Factory Manufacture of 1080P Wireless SMS MMS GPRS GSM 4G Hunting Camera Wildlife 4G Trail Camera Animal Camera, Hunting Sensor

Basic Info

Model NO.	BL-480LP
HS Code	8525802100
Production Capacity	50000/Year

Product Description

High quality 1080P Wireless SMS MMS GPRS GSM 4g hunting camera wildlife 4g trail camera

Support 4G 3G and 2G network.
Time lapse: 3 timers.
4-8months (4×AA~12×AA).
Hightlight:
1.Send photos to Mobile phone (VGA or QVGA image) and email ID ( Max 3 number and email address).
2.Send video to 1-3 Email ID(SSL/TSL support, Only original image or 6s 640*360 video can be sent,if need to send video,
please choose video mode and VGA resolution, and 6s video length).

3.Version for America
4G FDD-LTE frequency: B2 B4 B5 B12 B17
3G WCDMA frequency: B2 B4 B5
2G GSM Network: 850/1900

Version for Europe
4G FDD-LTE frequency: B1 B3 B5 B7 B8 B20
3G WCDMA frequency: B1 B5 B8
2G GSM Network: 850/900/1800/1900.

Supporting GPS: Latitude and longitude will be displayed on each picture.



Specifications:

GPS function: Supporting, camera will read when camera is on test mode
MMS Function: 1-3 mobile ID(only sending VGA and QVGA image)
SMTP function: 1-3 Email ID(SSL/TSL support, Only original image or 6s 640*360 video can be sent, if need to send video, please choose video mode and VGA resolution, and 6s video length)
Image Sensor: 5 Mega Pixels Color CMOS
Effective Pixels: 2592*1944
Day/Night Mode: Yes
IR range: 20m
IR Led: 54pcs
Memory: SD Card (8MB - 32 GB)(not included)
Operating remote control: 7 button
Lens (Regular lens model): F=1.8; FOV=90°; NO IR-Cut-Remove (at night)
LCD Screen: 2.0" TFT, RGB, 262k
PIR Sensitivity: 3 sensitive levels: High / Normal / Low
PIR distance: 20m
PIR Angle: 120°
Picture size: 5MP/8MP/12MP =2592x1944/3264x2448/4032x3024
Picture Format: JPEG
Video resolution: 1080P (1920x1080): 30FPS, 720P (1280x720):30FPS, 640x480
Video Format: MOV H.264
Video Length: 5-30sec. programmable
Shooting Numbers: 1-3
Trigger Time: 0.6s
Trigger Interval: 3s-60min
Camera + Video: Yes
Time lapse: supporting
Timer Setting: 3 Timers
Device Serial No.: Yes
Built-in Speaker: Yes
Recording Voice: ON/OFF
Operation Power: Battery: 6V; DC: 6V
Battery Type: 12AA
Stand-by Current: 0.035mA
Stand-by Time: 4-8months (4xAA~12×xAA)
Auto Power Off: auto switch to mode "OFF" in 180s without any operations
Power Consumption: IR LEDs Off (Photo: 200mA; Video: 200mA)
IR LEDs On (Photo: 1.2A)
Video: 1.2A
Interface: HDMI out/USB/SD Card/DC Port
Mounting: Strap; Tripod
Storage temperature: -30 °C to 60°C
Operation Humidity: 5%-90%
Waterproof spec: IP66
Certification: CE FCC RoHs
